Model |
Tube Outside diameter (mm) |
Tube inside diameter (mm) |
The maximum length (m) |
The Long (mm) |
Screw inside diameter (mm) |
Screw Outside diameter (mm) |
|
PU-0604-E |
6 |
4 |
3-15 |
40 |
31/37 |
D+2*A |
|
PU-0805-E |
8 |
5 |
3-15 |
40 |
37/50 |
D+2*A |
|
PU-1065-E |
10 |
6.5 |
3-15 |
40 |
50/70 |
D+2*A |
|
PU-1208-E |
12 |
8 |
3-15 |
40 |
50/70 |
D+2*A |
◆Spring tube product characteristics
·Through the air, water, oil and other media.
·It has good chemical stability, oil resistance, water resistance, solvent resistance, etc.
·Spring tube with good resilience, deformation remains keep in small size range after repeated use,.
·Spring tube with the characteristics of small volume, not occupy a space, lift long distances.
◆Matters needing attention:
·Don't let the spring tube stretch too much,otherwise it will make the spring tube deformation, affect its flexibility.
·Please be careful for using where the working environment temperature is too high (>55 ℃) or be full of chemical gas, because it may lead to a hose soften and the pressure of resistance drop dramatically.
·Please be careful to use in the workplace where the medium temperature is too high (>55 ℃) or fluid with corrosive components (such as alkali, acid, corrosion resistance strong solvent, etc.), because there will be the risk of hose rupture.
